940 Panel

The 940 Panel is a structural roof or wall panel with 1.5" deep ribs, 7.2 " o.c. for an overall cover width of 36.0". The panel is installed with exposed fasteners. The panel is available straight, curved convex, curved concave or serpentine (curved convex & concave)

Features
  • Panel Cover Width: 36"


  • Straight Length: Cut to customer specifications (5'- 0" min.; less than
    5'- 0" available w/ surchurge).

  • Finish: Kynar   500    (solid or metallic)


  • Colors: Choice of 30 standard colors


  • Curving:

    • Convex - 24" min. radius

    • Concave - 24" min. radius

    • Panel Arc Length: 26'- 0" max.

    • Not recommended for 26 ga. steel

or pre-finished aluminum


  • Mitered Corners: Factory engineered and fabricated from same material as panels; available in straight or curved panels


  • Serpentine: Curved convex and concave


​     Subject to Minimum Quantities


  • Galvalume  Clear Coat available as Unpainted Only


  • Minimum radius will vary with gauge and intrinsic properties of the specific substrate
