Type N Roof Deck

Type N Roof Deck is a structural deck panel with 3" deep ribs, 8 " o.c. for an overall cover width of 24". The panel is available crimp curved (convex - typical)

Features
  • Panel Cover Width: 24"


  • Panel Arc Length: Cut to customer specifications (26'- 0" max.). Inquire if longer required.


  • Finish: G60 or G90 Galvanized, or galvanized plus prime painted (min. quantities apply)


  • Plain or Acoustical


  • Curving:

    • Convex or Concave

    • 26'- 0" min. radius (22 ga.)

    • 50'- 0" min. radius (20 ga.)

    • 75'- 0" min. radius (18 ga.)


Minimum radius will vary with gauge and the
intrinsic properties of the specific substrate (tensile strength and hardness.) For example, 33 ksi steel will curve to a tighter radius than 50 ksi steel.



  • Optional Services:

    • Deck Layout Drawings

    • Toll Curving - We can curve your deck, but deck must be 50 ksi or less. ( 40 ksi is ideal)


  • Straight Metal Deck
